TU16 Concrete Mixer
Product description：
TMG utility vehicle products are underground mining auxiliary equipment developed for special purposes and targets, such as auxiliary transportation, auxiliary operation and auxiliary service in underground mines. They are are suitable for underground tunnel mines operation.The cab compartment is designed according to ISO ROPS/FOPS standards to ensure personnel safety. TMG series utility vehicle products covers:miner carrier, lift scissor,crane,logistics vehicle,scaler,concrete mixer,lube tank,maintenance vehicle, shotconcrete, etc with interchangeable chassis from 3 ton to 15 ton.
Product data
| Utility Vehicle Model | TU16 Concrete Mixer |
| Overall Dimension | 7411 x1840-2200x2269 mm |
| Operation Weight | 13000 kg |
| Rated Power | 112 kw/2300 rpm |
| Max Traction | `120 KN |
| Service Brake | Full hydraulic wet multi-disc on each wheel, spring brake, hydraulic release |
| Parking Brake | Controlled by park brake button in cabin |
| Emergency Brake | Has same theory as park brake; difference is when it's applied, a solenoid valve will work and make the engine stop |
| Tyre | 12.00 x 24-28PLY |
| Steering Angle | ±40° |
| Inner turnng radius | 3450±150mm |
| Out turning radius | 7850±150mm |
| Working System Effective Capacity | 1-10 m3 |
| Total Volume | 2.5-15 m3 |
| Diameter: | 1.4-2.3 m |
