Variable-distance outriggers enhance stability and prevent overturning.
Full computer control with large color screen; self-diagnosis improves reliability and fault-finding.
Front/rear drive axles with 4WD and 4WS, supporting front-wheel, 4-wheel, and crab steering.
High-strength self-developed engineering chassis, with strong load-bearing, passing, and climbing capacities.
Real dual-power system allows wet spraying without 380V power supply.
Key components (hydraulic main pump, electrical controller, manipulator cylinder, main valve group) are imported, enhancing reliability.
Internationally advanced hydrostatic drive system enhances drivability.
| Specification | Boom Structure | Boom and jib pitch, jib telescopes | |
| Jet Height(m) | 13 | ||
| Jet width(m) | 27 | ||
| Boom elevation angle( °) | -15/+35 | ||
| Jib elevation angle( °) | +5°-115° | ||
| Boom rotation angle( °) | 0-330° | ||
| Axial rotation angle of nozzle( °) | 360° | ||
| ertical axial swing angle of nozzle( °) | 240° | ||
| Swinging angle of nozzle( °) | ±4° | ||
| Front outrigger span(m) | 1800～2800 （Variabledistance outrigger） | ||
| Rear outrigger span(m) | 1800 | ||
| Span of front and rear outriggers(mm) | 3900 | ||
