TM450 Rigid Concrete Mixer
Product description：
TMG utility vehicle products are underground mining auxiliary equipment developed for special purposes and targets, such as auxiliary transportation, auxiliary operation and auxiliary service in underground mines. They are are suitable for underground tunnel mines operation.The cab compartment is designed according to ISO ROPS/FOPS standards to ensure personnel safety. TMG series utility vehicle products covers:miner carrier, lift scissor,crane,logistics vehicle,scaler,concrete mixer,lube tank,maintenance vehicle, shotconcrete, etc with interchangeable chassis from 3 ton to 15 ton.
Product data
| Utility Vehicle Model | TM450 Rigid Concrete Mixer |
| Outline Dimension | 6750x2360x2450 mm |
| Weight | 14000 kg |
| Operation Weight | 24000 kg |
| Effective Capacity | 4.5 m3 |
| Engine Power | 160 kw |
| Dump Height | 1800 mm |
| Tread | 1400/3300 mm |
| Min.Clearance | 300 mm |
| Mixer rpm | 13-18 r/min |
| Gradeability | 30% |
| Max Speed | 27 km/h |
| Inner turnng radius | 2750 mm |
| Out turning radius | 5300 mm |
| Driven Method | 4x4 |
Inquiry Now
If you have any questions or needs about the product, please fill in the following form and we wll contact you as soon as possible.
